PALBOARD® Terra

PVC composite panel with climate-positive UBQ™

The world’s first composite panel made with unsorted household waste, diverted from landfills and recycled PVC.
The PALBOARD Terra substrate is made with UBQ™, the only material upcycled from 100% unsorted waste. Utilizing trash and turning it into a sustainable resource.

PALBOARD Terra is engineered for wide-format printing and for mechanical fabrication. Create displays and graphics with a reduced carbon footprint.

GET FREE SAMPLE

UBQ Materials, climate tech developer of advanced materials made from organic and unrecyclable waste. Providing a sustainable substitute to plastic.

You see trash. We see an opportunity.

PALBOARD Terra is an ecological alternative to conventional sign & display substrates.
Making it easy for designers to accomplish their sustainability goals.

  • Preventing unsorted household waste from landfills.
  • Combining it with recycled PVC.
  • Turn it into durable plastic sheets.
You see trash. We see an opportunity.

Get Your Plastic Waste Collected And Repurposed

Partner with us in our effort to divert plastic waste from landfill.
We repurpose end-of-life polycarbonate and PVC scraps into durable, redesigned products.

This is the essence of a circular economy.
Partner with us and become a part of the solution.
Polycarbonate/PVC repurpose request form

Get Your Plastic Waste Collected And Repurposed

PRODUCT DETAILS

PropertyMethod*ConditionsUnitsValue
Physical
DensityASTM D-792g/cm30.58 - 0.62
Water absorptionASTM D-57024 hr @ 23°C% 3mm - 0.5
5mm - 0.8
Mechanical – Machine direction
Flexural modulusASTM D-790MPa1600
Shore hardnessASTM D-2240Shore D60
Thermal
Service temperature range°C -10 to 55
Heat deflection temperatureASTM D-648Load: 1.82 MPa°C62
Coefficient of linear thermal expansionASTM D-69610-5/°C6.7
Electrical
Surface resistanceASTM D-257Ohm4.1x1014
Standard Dimensions Note
* Other Dimensions Available Upon Request With Minimum Order Requirements

Standard Dimensions

Type:Standard Sizes
Thickness:3,5,10 mm
Length:2,440 mm / 3,050 mm
Width:1,220 mm / 1,500 mm / 2,030 mm

Standard Color chart

Color
White / Grey
White / Grey / White
